Product Advantage

The X1-IES supports up to 200% PV input and EPS output for 10 seconds, enabling superior energy utilization during peak loads 少妇小说在线. AI readiness and VPP integration capabilities future-proof your energy system while ensuring seamless scalability.

少妇小说免费

少妇小说免费 - Assured Reliability

IP66 protection degree
Type II SPD on AC&DC side
AFCI protection (optional)
UPS-level switchover time<10ms

Smart Management

Al ready, forecasting solar generation and home consumption for
smart energy management strategy control*
VPP ready with a variety of compatibility(OpenADR, IEEE2030. 5, FCAS, API)** 少妇性活BBBBBBBBB小说.
Smart loads management (e. g. , heat pump, smart EV charger) 少妇小说免费.
Micro-grid support for real-time grid/off-grid balancing
Wireless meter compatibility
Global MPP scan for optimal energy harvest

"免费阅读完整版" Flexible Adaptability

All-in-one, plug-and-play design
Max BBBBBBBBB情节. 20A DC input current for high power solar panel.

"少妇小说在线" High Performance

Max. 50A charge/discharge current
200% oversizing and 200% PV input power
Up to 200% EPS output for 10s
Low start-up voltage for longer operation
Cycle life > 6000 times

AC INPUT & OUTPUT(ON-GRID)

Rated output power	2500 W
Rated AC voltage	1/N/PE,220/230/240V

EPS(OFF-GRID) OUTPUT(WITH BATTERY)

Rated EPS output power	2500 VA
Peak EPS output power	2 times of rated power, 10 s
Switchover time	<10 ms

BATTERY MODEL

Battery type	Li-ion (LFP)
Max Charge / Discharge current	50 A
Ingress protection	IP66

GENERAL

Dimensions (W x H x D)	717x350x210 mm
Net Weight	26.2 kg

X1-IES-3K

PV INPUT
Max. recommended PV array power
6.0 kWp
MPPT voltage range
40~560 V
Number of MPP. trackers / strings per MPPT
2/(1/1)
Max. input current per MPPT
20 A/20 A
AC INPUT & OUTPUT(ON-GRID)
Rated output power
3000 W
Rated AC voltage
1/N/PE,220/230/240V
EPS(OFF-GRID) OUTPUT(WITH BATTERY)
Rated EPS output power
3000 VA
Peak EPS output power
2 times of rated power, 10 s
Switchover time
<10 ms
BATTERY MODEL
Battery type
Li-ion (LFP)
Max Charge / Discharge current
50 A
Ingress protection
IP66
GENERAL
Dimensions (W x H x D)
717x350x210 mm
Net Weight
26.2 kg

"少妇性活BBBBBBBBB小说" X1-IES-3.7K

PV INPUT
Max. recommended PV array power
7.4 kWp
MPPT voltage range
40~560 V
Number of MPP. trackers / strings per MPPT
2/(1/1)
Max. input current per MPPT
20 A/20 A
AC INPUT & OUTPUT(ON-GRID)
Rated output power
3680 W
Rated AC voltage
1/N/PE,220/230/240V
EPS(OFF-GRID) OUTPUT(WITH BATTERY)
Rated EPS output power
3680 VA
Peak EPS output power
2 times of rated power, 10 s
Switchover time
<10 ms
BATTERY MODEL
Battery type
Li-ion (LFP)
Max Charge / Discharge current
50 A
Ingress protection
IP66
GENERAL
Dimensions (W x H x D)
717x350x210 mm
Net Weight
26.2 kg

"少妇小说免费" X1-IES-5K

PV INPUT
Max. recommended PV array power
10.0 kWp
MPPT voltage range
40~560 V
Number of MPP. trackers / strings per MPPT
3/(1/1/1)
Max. input current per MPPT
20A/20A/20 A
AC INPUT & OUTPUT(ON-GRID)
Rated output power
5000 W
(4600 for VDE41054999 for AS4777)
Rated AC voltage
1/N/PE,220/230/240V
EPS(OFF-GRID) OUTPUT(WITH BATTERY)
Rated EPS output power
5000 VA
Peak EPS output power
2 times of rated power, 10 s
Switchover time
<10 ms
BATTERY MODEL
Battery type
Li-ion (LFP)
Max Charge / Discharge current
50 A
Ingress protection
IP66
GENERAL
Dimensions (W x H x D)
717x350x210 mm
Net Weight
26.4 kg

X1-IES-6K

PV INPUT
Max. recommended PV array power
12.0 kWp
MPPT voltage range
40~560 V
Number of MPP. trackers / strings per MPPT
3/(1/1/1)
Max. input current per MPPT
20 A/20 A/20 A
AC INPUT & OUTPUT(ON-GRID)
Rated output power
6000 W
Rated AC voltage
1/N/PE,220/230/240V
EPS(OFF-GRID) OUTPUT(WITH BATTERY)
Rated EPS output power
6000 VA
Peak EPS output power
2 times of rated power, 10 s
Switchover time
<10 ms
BATTERY MODEL
Battery type
Li-ion (LFP)
Max Charge / Discharge current
50 A
Ingress protection
IP66
GENERAL
Dimensions (W x H x D)
717x350x210 mm
Net Weight
26.4 kg

X1-IES-8K

PV INPUT
Max. recommended PV array power
16.0 kWp
MPPT voltage range
40~560 V
Number of MPP. trackers / strings per MPPT
3/(1/1/1)
Max. input current per MPPT
20 A/20 A/20 A
AC INPUT & OUTPUT(ON-GRID)
Rated output power
8000 W
Rated AC voltage
1/N/PE,220/230/240V
EPS(OFF-GRID) OUTPUT(WITH BATTERY)
Rated EPS output power
8000 VA
Peak EPS output power
2 times of rated power, 10 s
Switchover time
<10 ms
BATTERY MODEL
Battery type
Li-ion (LFP)
Max Charge / Discharge current
50 A
Ingress protection
IP66
GENERAL
Dimensions (W x H x D)
717x350x210 mm
Net Weight
26.4 kg
